✅ Product Description
The Comen CM1200B is a high-performance 12-channel ECG machine designed for precision, reliability, and efficiency in clinical settings. It features a 5.6” LED screen, 300 ECG memory, support for SD card storage (up to 40,000 cases), and offers multiple recording modes with accurate data capture. Ideal for hospitals, diagnostic centers, and emergency response units.
🔍 Features
-
5.6″ LED display with clear ECG waveform visibility
-
Lead status indicator
-
Simple keyboard layout with tilt support
-
Internal memory for 300 ECG records
-
Optional SD card storage (up to 40,000 cases)
-
Advanced digital filters (EMG, AC, Drift, Low Pass)
-
120-second ECG review and print
-
Supports 215mm wide roll paper
-
USB for data transfer & PC ECG management
-
Working modes: Auto, Manual, Rhythm
-
High recording sensitivity: 10mm/mV ±0.2%
⚙️ Technical Specifications
-
Power Supply:
-
AC: 100–240V, 50/60Hz
-
DC: 14.8V, 3700mAh rechargeable lithium battery
-
-
Input Way: Floating and defibrillation protection
-
Lead: Standard 12-lead
-
Patient Leak Current: ≤10µA
-
Input Impedance: ≥50MΩ
-
Frequency Response: 0.05Hz–150Hz (±3dB)
-
Time Constant: ≥3.2s
-
CMRR: ≥60 dB
-
EMG Interference Filter: >35dB
-
Size: 314 × 320 × 85 mm
-
Net Weight: 2.25 kg
🧾 Recording & Printing
-
Recording Modes: Auto / Manual / Rhythm
-
Recording Way: Thermal printing
-
Paper Speed: 25 mm/s, 50 mm/s
-
Printing Modes:
-
12×1
-
6×2
-
Rhythm: 12, 10, 8, 6-channel options
-
-
Measurements:
-
HR, PR, P Duration, P/Q Interval, QRS Axis, T Axis, QTc, RV5/SV1
-
-
Sensitivity Options: 5, 10, 20, 40 mm/mV (error ±5%)
🧰 Usage Type
-
Clinical ECG diagnosis
-
Hospital OPD/IPD
-
ICU/CCU monitoring
-
Emergency care
-
Mobile clinics
🛡️ Safety & Build
-
Safety: Class I CF (patient-applied part)
-
Input Circuit: Isolation & defibrillation protection
-
Battery Life: 150 tests per charge (approx.)
